LED Batten Specifications data with 600mm length
| Version | Item No. | Description | MM=Color temp. | Luminous flux | |
| □ | Extra | B2-LD2FT20-MMK-AP | 2’ Diffused LED Batten light,
Full Voltage100-277V 50/60Hz Tri-Power: 12W-16W-20W 3CCT: 3500K-4000K-5000K 0-10V Dimming |
3000K
4000K 5000K |
133m/w
150lm/w 142lm/w |
LED Batten Specifications data with 1200mm length
| Version | Item No. | Description | MM=Color temp. | Luminous flux | |
| □ | Extra | B2-LD4FT40-MMK-AP | 4’ Diffused LED Batten light,
Full Voltage100-277V 50/60Hz Tri-Power: 28W-36W-40W 3CCT: 3500K-4000K-5000K 0-10V Dimming |
3000K
4000K 5000K |
133m/w
150lm/w 142lm/w |
LED Batten Specifications data with 1500mm length
| Version | Item No. | Description | MM=Color temp. | Luminous flux | |
| □ | Extra | B2-LD8FT75-MMK-AP | 8’ Diffused LED Batten light,
Full Voltage100-277V 50/60Hz Tri-Power: 53W-63W-75W 3CCT: 3500K-4000K-5000K 0-10V Dimming |
3000K
4000K 5000K |
133m/w
150lm/w 142lm/w |
