LED Vapor Tight Fixtures
Vapor Tight Light Fixtures provide robust illumination for damp, dusty, or corrosive settings like food plants, warehouses, and garages. With IP65 enclosures, rust-resistant, they endure tough conditions while delivering consistent brightness. Energy-efficient LEDs ensure longevity and low upkeep, meeting industrial safety standards for reliable, maintenance-free operation in demanding environments.
-
5-Year Warranty
-
0-10V Dimming
-
IP65 Waterproof, IK09 Protection
-
PC Housing +PC Diffuser, 94V0 materials
UL Listed LED Vapor Tight Fixtures
Where to Use Fanxstar Vapor Tight Light Fixtures
Designed for Easy Installation
-
Surface & Suspended: Supports surface mounting (ceiling) and suspension.
-
Knockouts for Conduit : Features pre-installed 1/2” knockouts on both ends of the housing for easy connection to standard American metal conduit
-
Captive Latches: Tool-free maintenance enabled by stainless steel Clips.
Series Specifications (2ft / 4ft / 8ft)
| Model Size | Power | Lumens | Voltage | CCT | Dimming |
| 2ft (24″) | 12-20W | 3,200lm | 120-277V | 3500K-4000K-5000K | 0-10V |
| 4ft (48″) | 20-60W | 9,600lm+ | 120-277V / | 3500K-4000K-5000K | 0-10V |
| 8ft (96″) | 60W-120W | 19,200lm+ | 120-277V | 3500-4000K-5000K | 0-10V |
Maximize Energy Savings
–Built-in microwave motion sensor
Equipped with a built-in microwave sensor that automatically dim the light to 10% when no motion is detected, and instantly restores to 100% brightness upon sensing movement, achieving significant energy savings.
–Emergency Battery Backup
Offers an optional 90-minute UL-certified emergency battery pack. In the event of a main power failure, it automatically switches to battery power, providing continuous, reliable illumination.
–2-in-1 Solution
This series can integrate the Motion Sensor and Emergency Battery Backup into a single, unified system, offering both intelligent energy management and critical safety backup in one fixture.
This integrated design provides a cost-effective and space-saving answer to the need for smart, safe lighting in commercial and industrial environments.
