UV Linear Led Light M4B
Our UV Linear LED Light M4B, crafted with precision using Aluminium 6063 and a 395nm UVA & PMMA cover, delivers exceptional performance in industrial curing and counterfeit detection for enterprises, backed by Fanxstar’s rigorous quality control, OEM/ODM capabilities, and dedicated technical support to meet commercial and industrial lighting needs.
LED Linear Batten Key Features and Benefits
- Aluminum Housing with PMMA Diffuser
- Seamless splicing linear lighting system
- Black Color housing with with 395nm UVA
- ENEC approved Flicker-free driver
- 5 Years Warranty
Linear Lighting Batten Description
UV Linear LED Light M4B by Fanxstar is constructed with high-grade Aluminium 6063 for durable heat dissipation and structural stability and 395nm UVA chips paired with a PC/PMMA cover for efficient UV transmission.
Our M4B is specially designed for the stage which can enhance the atmosphere when dancers are performing. It can also be used to identify the currency by using the UV black light.
As a professional UV lighting manufacturer and factory, Fanxstar provides this M4B series with core advantages: customizable wattages/lengths for bulk wholesale, latest invention of high-quality CB/CE/UKCA/RCM with IP20 & IK08, long 50,000-hour LED lifespan to reduce maintenance costs, and one-stop supply support including pre-project technical consultation and post-sales service to meet global industrial clients’ project needs.
Led Linear Light Ceiling Specification
| Item | Part Number | M4-2FT20-395-UV | M4-4FT40-395-UV | M4-5FT60-395-UV |
| Description | Magfit black Batten with UV395 | |||
| Working | Mode of Operation | Null(Stand) | ||
| Input | Voltage&Frequency | 220-240Vac, 50/60Hz | ||
| Wiring Connection | Series connection | |||
| Output | Light Source | High lumens SMD2835 | ||
| Color Temperature | UVA395nm, 275 or 405nm as ootions | |||
| Luminous Flux | Non | |||
| Power Consumption | 20W | 40W | 60W | |
| Controls | Protection | Overcharge, low voltage disconnects, overcurrent, short circuit | ||
| Multimode | On/off, Brightness Control | |||
| Physical | Construction | Alu6063+PMMA | ||
| Mounting | Surface mounted – ceiling / wall / Suspend | |||
| Colour | Black RAL9005 | |||
| Dimensions L x W x H(mm) | 600×38×57 | 1200×38×57 | 150×38×57 | |
| IP/IK Rating | IP20 & IK08 | |||
| Weight | 0.73kg | 0.95kg | 1.15kg | |
| Warranty | 5 years on product | |||
| Environment | Operating Temperature | -20° to 50°C | ||
| Relative Humidity | -10 to 95% | |||
| Compliance | Standards | CB/CE/UKCA/RCM | ||
| Accessories | Standard | BK01M4, IPC3XM4, SC03M4 | ||
| Optional | JP03M4 | |||
Need a Precision UV Solution for Your Unique Application?
LED UV Linear Lighting M4B Detail Display
Magnetic Led Linear Fixtures Dimensions
Linear LED Batten Packing List
| Single Size (L*W*H) | N.W/PCS | BOX Size (L*W*H) | CTN Size (L*W*H) | PCS/CTN | G.W/CTN |
| 600×38×57mm | 0.73kg | 670x41x61mm | 690x230x150mm | 10pcs | 9.7kg |
| 1200×38×57mm | 0.95kg | 1270x41x61mm | 1290x230x150mm | 10pcs | 12.3kg |
| 1500×38×57mm | 1.15kg | 1570x41x61mm | 1590x230x150mm | 10pcs | 14.7kg |
Led Linear Bracket Light Accessories
